Open Burners
• Nickel plated cast iron 28 mj dual-flame ring burners
• Flame failure device standard (pilots optional extra)
• Variable flame control valve with low flame setting
• Heavy duty cast iron trivets
• Pressed 0.7mm 304 stainless steel spillage bowls
Overall Construction
• Heavy duty construction
• Welded 1.2mm 304 stainless steel front hob
• Front and side panels 0.9mm 304 stainless steel
• Splashback 1.2mm 304 stainless steel
• Stainless steel legs with 55mm height adjustment range
• Sedcondary catchment tray 0.9mm stainless steel
Dimensions
• 300mm x 800mm x 1100mm H
• 300mm x 800mm x 560mm H (benchtop)
• Working height 900mm
• Weight 46kg
• Packed dimensions 640mm x 860mm x 1260mm H
• Packed weight 66kg
Connections
• Gas 3/4” BSP male
• 180mm from right, 50mm from rear, 600mm from floor
• Benchtop model gas connection: 60mm from bottom
• Supplied with gas regulator (specify Nat or LP on order)
