Griddle/Hotplate
• 18 mj burners with pilot, FFD and piezo ignition
• Variable flame control valve with low flame setting
• 16mm thick mild steel griddle plate
• Top weld sealed hotplate sections
• CS-6P3C plate: 590mm x 540mm; 0.32m2 cooking area
• 2mm 304 stainless steel splash guards
• Griddle oil bin 1.2mm stainless steel
Chargrill/Barbecue
• 33 mj burners with pilot, FFD and piezo ignition
• Variable flame control valve with low flame setting
• Two piece burner with cast-iron heat distributing hood
• Heavy duty cast iron ‘diamond’ grates 147mm x 540mm
• CS-6P3C bbq: 280mm x 520mm; 0.15m2 cooking area
• 2mm 304 stainless steel splash guards
• Chargrill undertray 0.9mm stainless steel
Dimensions
• 900mm x 800mm x 1100mm H
• 900mm x 800mm x 560mm H (benchtop)
• Working height 900mm
• Weight 115kg
• Packed dimensions 940mm x 860mm x 1260mm H
• Packed weight 140kg
